PACSystems™ RSTi-EP Analog Input, 4 channel Voltage/Current 12 Bits 2, 3, or 4 Wire

The RSTi-EP remote I/O system is ideal for Industrial Internet applications. It features an extended operating temperature range, enhanced diagnostics, plug-and-play connectivity and high channel density.

Analog Input Count & Type

4 point; Voltage/Current

Resolution & Speed

12 bit; 1mS

Current Consumption Isys & Iin

8mA 20.4-28.8VDC; 25mA + sensor supply 24VDC

System Redundancy

PNSR

Additional Capabilities

Voltage (0 to 5 V, ±5 V, 0 to 10 V, ±10 V, 1 to 5 V, 2 to 10 V) Current (0 to 20 mA, 4 to 20 mA)

Features

• Support for PROFINET RT, PROFIBUS, Modbus TCP and EtherCAT
• Extended operating temperature range, enhanced diagnostics
• High-speed system bus reads up to 256 DI/DOs in 20 mS
• DIN rail mounted
• Plug-and-Play Installation
