PACSystems™ RSTi-EP Analog Input, 4 channel TC 16 Bits with Diagnostics 2, 3, or 4 Wire

The RSTi-EP remote I/O system is ideal for Industrial Internet applications. It features an extended operating temperature range, enhanced diagnostics, plug-and-play connectivity and high channel density.

Analog Input Count & Type

4 point; Thermocouple with Diagnostics

Resolution & Speed

16 bit; 36 to 240 mS adjustable

Current Consumption Isys & Iin

8mA 20.4-28.8VDC; 20mA 24VDC

System Redundancy

PNSR

Additional Capabilities

Thermocouple Types J, K, T, B, N, E, R, S, L, U, C, mV

Features

• Support for PROFINET RT, PROFIBUS, Modbus TCP and EtherCAT
• Extended operating temperature range, enhanced diagnostics
• High-speed system bus reads up to 256 DI/DOs in 20 mS
• DIN rail mounted
• Plug-and-Play Installation
